Siemens SIMOCODE pro System Manual

Tables
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
A-7
80 Contactor controls Contactor control 1 QE1
Dependent on the control
function
81 Contactor control 2 QE2
82 Contactor control 3 QE3
83 Contactor control 4 QE4
84 Contactor control 5 QE5
85 Reserved
86 Reserved
87 Reserved
88 Lamp controls Display - QLE<< (ON <<)
Dependent on the control
function
89 Display - QLE< (ON <)
90 Display - QLA (OFF)
91 Display - QLE> (ON >)
92 Display - QLE>> (ON >>)
93 Display - QLS (fault) BU1 BU2
94 Reserved
95 Reserved
96 Status information - General Status - General fault BU1 BU2
97 Status - General warning BU1 BU2
98 Status - Device BU1 BU2
99 Status - Bus BU1 BU2
100 Status - PLC/PCS BU1 BU2
101 Status - Motor current flowing IM UM
102 Reserved
103 Reserved
104 Status information - Receive Status - ON <<
Dependent on the control
function
105 Status - ON <
106 Status - OFF
107 Status - ON >
108 Status - ON >>
109 Status - Start active BU1 BU2
110 Status - Interlocking time active All reversing starters and
positioners
111 Status - Change-over pause active Star-delta,
Dahlander,
Pole changing starter
112 Status - Runs in open direction
Dependent on the control
function
113 Status - Runs in close direction
114 Status - FC
115 Status - FO
116 Status - TC
117 Status - TO
118 Status - Cold starting (TPF) BU1 BU2
119 Status - OPO BU2
120 Status - Remote mode BU1 BU2
No. Designation Designation Information
Table A-3: Socket assignment table - digital (Cont.)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
