Tables
SIMOCODE pro
A-8 GWA 4NEB 631 6050-22 DS 03
121 Status information - Protection Status - Emergency start executed IM UM
122 Status - Cooling down period active IM UM
123 Status - Pause time active IM UM
124 Status information - Miscellaneous Status - Device test active BU1 BU2
125 Status - Phase sequence 1-2-3 UM
126 Status - Phase sequence 3-2-1 UM
127 Status - DM-F enabling circuit DM-F
128 Events - Protection Event - Overload operation IM UM
129 Event - Unbalance IM UM
130 Event - Overload IM UM
131 Event - Overload + phase failure IM UM
132 Event - Internal earth fault IM UM
133 Event - External earth fault EM
134 Event - Warning ext. earth fault EM
135 Event - Thermistor overload Th
136 Event - Thermistor short circuit Th
137 Event - Thermistor open circuit Th
138 Event - TM warning T> TM
139 Event - TM Trip T> TM
140 Event - TM sensor fault TM
141 Event - TM out of range TM
142 Reserved
143 Reserved
144 Events - Level monitoring Event - Warning I> IM UM
145 Event - Warning I< IM UM
146 Event - Warning P> UM
147 Event - Warning P< UM
148 Event - Warning cos phi< UM
149 Event - Warning U< UM
150 Event - Warning 0/4-20 mA> AM
151 Event - Warning 0/4-20 mA< AM
152 Event - Trip I> IM UM
153 Event - Trip I< IM UM
154 Event - Trip P> UM
155 Event - Trip P< UM
156 Event - Trip cos phi< UM
157 Event - Trip U< UM
158 Event - Trip 0/4-20 mA> AM
159 Event - Trip 0/4-20 mA< AM
160 Event - Stalled rotor IM UM
161 Reserved
162 Reserved
163 Event - No start possible BU1 BU2
164 Event - No. of starts > BU1 BU2
No. Designation Designation Information
Table A-3: Socket assignment table - digital (Cont.)
