Tables
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
A-9
165 Event - Just one start possible BU1 BU2
166 Event - Motor operating hours > BU1 BU2
167 Event - Motor stop time > BU1 BU2
168 Event - Limit 1 BU2
169 Event - Limit 2 BU2
170 Event - Limit 3 BU2
171 Event - Limit 4 BU2
172 Events - Miscellaneous Event - External fault 1 BU1 BU2
173 Event - External fault 2 BU1 BU2
174 Event - External fault 3 BU1 BU2
175 Event - External fault 4 BU1 BU2
176 Event - External fault 5 BU2
177 Event - External fault 6 BU2
178 Reserved
179 Reserved
180 Event - Analog module open circuit AM
181 Event - DM-F safety-oriented tripping DM-F
182 Event - DM-F - Test requirement DM-F
183 Reserved
184 Events - Time stamp function Event - Timestamping function active + OK BU2
185 Reserved
186 Events - Miscellaneous Event - DM-FL safety o.k DM-FL
187 Event - PROFIsafe active DM-FP
188 Events - System interface Event - Configured operator panel missing BU1 BU2
189 Reserved
190 Warnings - Miscellaneous Warning - DM-F feedback circuit DM-F
191 Warning - DM-FL simultaneity DM-FL
192 Trip - General Trip - HW fault basic unit BU1 BU2
193 Trip - Module fault (e.g. IM, DM) BU1 BU2
194 Trip - Temporary components (e.g. memory
module)
BU1 BU2
195 Trip - Configuration fault BU1 BU2
196 Trip - Parameterization BU1 BU2
197 Trip - Bus BU1 BU2
198 Trip - PLC/PCS BU1 BU2
199 Reserved
200 Trip - Controlling Trip - Execution Time ON
Not for overload relays
201 Trip - Execution time OFF
202 Trip - FB ON
203 Trip - FB OFF
204 Trip - Stalled positioner Positioner
205 Trip - Double 0 Solenoid valve/positioner
206 Trip - Double 1 Solenoid valve/positioner
207 Trip - End position Solenoid valve/positioner
No. Designation Designation Information
Table A-3: Socket assignment table - digital (Cont.)
