5
05.01
5.10 Control module ”ANA module”
5-157
Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) – 05.01 Edition
2 sensors can be connected per axis
S X111: Axis 1 (sensors 1A, 1B)
S X112: Axis 2 (sensors 2A, 2B)
Table 5-28 Connectors X111, X112; respective 15–pin D–Sub socket connector
Pin X111 X112 Type
1)
Function
1 P24DS P24DS O Sensor supply with external +24 V
2 P24DS P24DS O Sensor supply with external +24 V
3 – – not assigned
4 – – not assigned
5 M24EXT M24EXT O Sensor supply with external 0 V
6 – – not assigned
7 – – not assigned
8 – – not assigned
9 M24EXT M24EXT O Sensor supply with external 0 V
10 M24EXT M24EXT O Supplementary pin for jumper, pins 10–11 for
3–conductor connection
11 PIST1BN PIST2BN I Analog actual value signal, reference
ground
12 PIST1BP PIST2BP I Analog actual value signal, max. range
0...10 V
13 M24EXT M24EXT O Supplementary pin for jumper pins 13–14 for
3–conductor connection
14 PIST1AN PIST2AN I Analog actual value signal, reference
ground
15 PIST1AP PIST2AP I Analog actual value signal, max. range
0...10 V
1) I: Input, O: Output
The inputs are differential inputs with 40 kΩ input resistance.
The input voltage range of the actual value inputs is 0...+10 V.
The power supply output has electronic short–circuit protection.
The supply output is dimensioned for a total current (4 sensors) of 200 mA.
Analog sensors
5 Control Modules
