5.10 Control module ”ANA module”
5-158
 Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) – 05.01 Edition
S X121: Axis 1
S X122: Axis 2
Table 5-29 Connectors X121, X122; 15–pin D–Sub socket connectors
Pin X121 X122 Type
1)
Function
1 P24RV1 P24RV2 O P24EXT switched, from X431.5
2 P24RV1 P24RV2 O P24EXT switched, from X431.5
3 P24RV1 P24RV2 O P24EXT switched, from X431.5
4 P24RV1 P24RV2 O P24EXT switched, from X431.5
5 M M Electronics ground
6 VSET1N VSET2N O Analog setpoint output, reference ground
7 VSET1P VSET2P O Analog setpoint output +/–10 V
8 M M Electronics ground
9 M24EXT M24EXT O M24EXT, from X431.6
10 M24EXT M24EXT O M24EXT, from X431.6
11 M24EXT M24EXT O M24EXT, from X431.6
12 – – Not assigned
13 M M Electronics ground
14 VACT1N VACT2N I Analog actual value input, reference
ground
15 VACT1P VACT2P I Analog actual value input, +/–10 V
1) I: Input, O: Output
The analog actual value inputs are differential inputs with 100 kΩ input
resistance.
The load capability of the 24 V outputs (P24RV1/2) is
S for an ambient temperature of 40 °C 2.0 A
S for an ambient temperature of 55 °C 1.5 A
For the average current value and a load duty cycle with 10 s duration.
It is permissible to linearly interpolate between the temperature transition points.
The short–time load capability of the 24 V output is 3.0 A (200 ms).
When overloaded, fuse F1900 or F1901 on the ANA control module is
destroyed.
The 24 V switched outputs for axes 1 and 2 are protected with a fine fuse
F1900 (axis 1) or F1901 (axis 2).
Value: 2.5 AF/250 V; 5x20 mm UL
Company: Wickmann–Werke GmbH
Annenstraße 113
58453 Witten
or
Postfach 2520
58415 Witten
Order No.: 19194
Analog setpoints
and actual values
Fuse
5 Control Modules
