6
05.01
6.1 Function overview and settings
6-166
Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) 05.01 Edition
OFF: Ready signal (X111 ready relay)
For S1.2 = OFF, the relay pullsin if the following conditions are fulfilled:
Internal main contactor CLOSED (terminals NS1 - NS2 connected, ter-
minal 48 enabled)
Terminal 63, 64=ON (energized)
No fault present (also not on FD 611 A standard, 611 U, resolver and 611
D drives or HLA modules).
FD with Standard interface or resolver is enabled in the ready setting
(terminals 663, 65)
For 840D/810D, the NCU must have runup
ON: Fault signal (X111 ready relay)
For S1.2 = ON, the relay pullsin if the following conditions have been fulfilled:
Internal main contactor CLOSED (terminals NS1 - NS2 connected, termi-
nal 48 enabled)
No fault present (also not on FD 611 A standard, 611U, resolver and 611
D drives and HLA modules).
FD with Standard interface or resolver is enabled in the ready setting
(terminals 663, 65)
For 840D and 810D, the NCU must have runup
OFF: Standard setting, regenerative feedback active
I/R modules: 16 KW to 120 KW are capable of regenerative
feedback.
UI module: 5 KW, 10 KW, 28 KW: The pulsed resistor
in the module is effective.
ON: Regenerative feedback disabled
I/R modules: 16 KW to 120 KW: Regenerative feedback operation is
inhibited
UI module: 5 KW, 10 KW: The pulsed resistor in the module is
inactive
Valid for all 5 KW and 10 KW UI from
Order number: 6SN11461AC000AA1.
Not valid for UI 28 KW. In this case, the external
pulsed resistor must be disconnected.
OFF: Standard setting for all NE modules, refer to S 1.1
ON: V
supply
= 480 V +6% / 10 %; V
DC
link
= V
supply
1.35 for infeed operation
V
DC
link
= 700 ... 750 V in regenerative feedback operation
Monitoring thresholds: (I/R, UI, monitoring modules)
Pulsed resistor on = 744 V; Pulsed resistor off = 718 V
V
DC
link
>> = 795 V
S1.4 overwrites the setting of S1.1
Comment: Uncontrolled operation in the infeed direction.
!
Warning
For operation with 480 V line supplies, it is extremely important that before
powering up (switching in the line supply), switch S1.4 = ON is set to ON, as
otherwise the infeed circuit in the NE module will be overloaded.
Switch S1.2
Switch S1.3
Switch S1.4
6 Infeed Modules
