6.1 Function overview and settings
6-168
Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) – 05.01 Edition
Sinusoidal current operation is only permissible, if the
following components are used:
Table 6-1 Combination for sinusoidal current operation (regenerative feedback into
the line supply)
I/R
16 kW
I/R
36 kW
I/R
55 kW
I/R
80 kW
I/R
120 kW
For internal
cooling:
For internal
cooling:
For internal
cooling:
For internal
cooling:
For internal
cooling:
6SN1145–
1BA01–0BA1
6SN1145–
1BA02–0CA1
6SN1145–
1BA01–0DA1
6SN1145–
1BB00–0EA1
6SN1145–
1BB00–0FA1
For external
cooling:
For external
cooling:
For external
cooling:
For external
cooling:
For external
cooling:
6SN1146–
1BB01–0BA1
6SN1146–
1BB02–0CA1
6SN1146–
1BB00–0DA1
6SN1146–
1BB00–0EA1
6SN1146–
1BB00–0FA1
HF reactor
16 kW
HF reactor
36 kW
HF reactor
55 kW
HF reactor
80 kW
HF reactor
120 kW
6SN1111–
0AA00–0BA1
6SN1111–
0AA00–0CA1
6SN1111–
0AA00–0DA1
6SN1111–
0AA00–1EA0
6SN1111–
0AA00–1FA0
Line filter for
sinusoidal
current
1)
16 kW
Line filter for
sinusoidal
current
1)
36 kW
Line filter for
sinusoidal
filter
1)
55 kW
Line filter for
sinusoidal
current
1)
80 kW
Line filter for
sinusoidal
current
1)
120 kW
6SN1111–
0AA01–2BA0
6SN1111–
0AA01–2CA0
6SN1111–
0AA01–2DA0
6SN1111–
0AA01–2EA0
6SN1111–
0AA01–2FA0
Line supply filter packages are available for the I/R modules. These line filter packages
comprise a line supply filter and an HF commutating reactor. If non–certified/authorized
components are used, then it is possible that the certificate, issued for this equipment, no
longer applies and that these components represent a potential hazard. Adapter sets are
available to adapt the line supply filter packages to the mounting surface and to the retai-
ning points of the previous filter modules (Order No., refer to Catalog NC 60)
Caution
It is only permissible to set squarewave current operation
for all of the
combinations which are not listed here (discontinued filter module
6SN11 11–0AA01–0_A_).
For all other operating modes, there is a danger of thermal overload.
Table 6-2 Power factor
I/R
Line–side
sinusoidal current operation
cos ϕ 0.98 cos λ = 0.97
I/R
Line–side
squarewave current
operation
cos ϕ 0.98 cos λ = 0.89
UI
cos ϕ 0.87 cos λ = 0.67
cos ϕ: The power factor only includes the basic fundamental
cos λ: Power factor includes the basic fundamental and harmonic components
1)
The HF commutating reactor must be externally mounted. (refer to Section 7.1.3).
The line filter is required in order to achieve the CE Conformance for the radio interference voltage.
