Siemens Simodrive 611 Planning Guide

4
05.01
4.1 Technical data
4-87
 Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) – 05.01 Edition
Table 4-4 Order No. assignment
PM type Power modules
Internal cooling External cooling
PM 8 A 6SN11 23 – 1AA00 – 0HA1 6SN11 24 – 1AA00 – 0HA1
PM 15 A 6SN11 23 – 1AA00 – 0AA1 6SN11 24 – 1AA00 – 0AA1
PM 25 A 6SN11 23 – 1AA00 – 0BA1 6SN11 24 – 1AA00 – 0BA1
PM 50 A 6SN11 23 – 1AA00 – 0CA1 6SN11 24 – 1AA00 – 0CA1
PM 80 A 6SN11 23 – 1AA00 – 0DA1 6SN11 24 – 1AA00 – 0DA1
PM 160 A 6SN11 23 – 1AA00 – 0EA1 6SN11 24 – 1AA00 – 0EA1
PM 200 A 6SN11 23 – 1AA00 – 0FA1 6SN11 24 – 1AA00 – 0FA1
PM 2x8 A 6SN11 23 – 1AB00 – 0HA1 6SN11 24 – 1AB00 – 0HA1
PM 2x15 A 6SN11 23 – 1AB00 – 0AA1 6SN11 24 – 1AB00 – 0AA1
PM 2x25 A 6SN11 23 – 1AB00 – 0BA1 6SN11 24 – 1AB00 – 0BA1
PM 2x50 A 6SN11 23 – 1AB00 – 0CA1 6SN11 24 – 1AB00 – 0CA1
4 Power Modules
