4
05.01
4.1 Technical data
4-86
Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) 05.01 Edition
Table 4-3 Technical data/power module, 2axis version
Internal cooling
External cooling
Cooling type
6SN 11231AB0.
6SN 11241AB0.
0HA1
0HA1
Non
ventila-
ted
0AA1
0AA1
Force
ventila-
ted
0BA1
0BA1
Force
ventila-
ted
0CA1
0CA1
Force
ventila-
ted
To use 1FT5 motors with control module 6SN11 180Ax11xxxx
Rated current
Peak current
A
A
4
8
7.5
15
12.5
25
25
50
Power loss, total/
internal/external
3)
W 70 / 27 /
43
105 / 40 /
64
174 / 67 /
107
364 / 124
/ 240
f
o
1)
X1
1)
kHz
%
3.3
55
3.3
55
3.3
55
3.3
55
To use 1FT6 motors/1FK6 motors with control module 6SN11 180Bx11xxxx
Rated current
Peak current
A
A
3
6
5
10
9
18
18
36
Power loss, total/
internal/external
3)
W 70 / 27 /
43
100 / 38 /
62
180 / 69 /
111
380 / 130
/ 250
f
o
1)
X1
1)
kHz
%
3.3
55
3.3
55
3.3
55
3.3
55
To use 1FT6 motors/1FK6 motors/1FN motors
with control module 6SN11 180Dxxxxxxx, 6SN11 18xNxxxxxxx
Rated current
Peak current
A
A
3
6
5
10
9
18
18
36
Power loss, total/
internal/external
3)
W 70 / 27 /
43
100 / 38 /
62
180 / 69 /
111
380 / 130
/ 250
f
o
1)
X1
1)
kHz
%
4
55
4
55
4
55
4
55
To use 1PH and 1FE1 motors and induction motors with control module 6SN11 18xNxxxxxxx
Rated current
Current for S640%
Peak current
A
A
A
3
3
3
5
5
8
8
10
16
24
32
32
Power loss, total/
internal/external
3)
W 76 / 28 /
48
118 / 42 /
76
226 / 74 /
152
538 / 184
/ 354
f
o
1)
X1
1)
kHz
%
3.2
55
3.2
55
3.2
55
3.2
55
General data for controlled infeed modules
Input voltage
Output voltage
Efficiency η
V
V
600/625/680 DC
3ph. 0 to 430 V
0.98
Module width
Max. crosssection
2)4)
Weight, approx.:
Internal cooling
External cooling
mm
mm
2
kg
kg
50
6/4
7
7
50
6/4
7
7
50
6/4
7
7
100
6/4
13.5
13.5

fo = inverter clock frequency
1) X1 = reduction factor of the current, current derating from inverter clock frequency f
0
of the power transistors (Fig. 4-2)
2) The 1st number is valid for cable lugs, the 2nd number is valid for finelystranded conductors without conn. sleeves.
3) If internal cooling or hose cooling is used, then only Pv
tot
should be considered.
4) For UL certification only use copper cables designed for an operating temperature of w 60
4 Power Modules
