Mounting
5
5.1 Converter
5.1.1
Mounting instructions f
or the converter
Description
Observe the conditions listed below in order to guarantee reliable, continuous and trouble-free
operation:
The converter is designed for installation in a control cabinet.
The converter is certi󹪝ed for use in environments with degree of pollution 2 without
condensation; i.e. in environments where no conductive pollution/dirt occurs. Condensation
is not permissible.
The converter ful󹪝lls degree of protection IP20 according to IEC60529.
Ensure that all converters and cabinets are grounded according to Section "EMC-compliant
installation (Page92)".
Use a conductive steel sheet no thinner than 2mm as the mounting plate.
Note
K
eep t
he cover of the integrated operator panel closed to protect the control buttons and the SD
card.
5.1.2 Mounting position
Description
NO
TICE
Overheating due to impermissible mounting position
The
conv
erter can overheat and therefore be damaged if mounted in an impermissible position.
Only mount the converter in a permissible position.
The converter supports vertical mounting only. Mount the converter vertically with the
integr
ated operator panel facing upwards.
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 99
