Requirement
• For activated user management (UMAC):
The function rights required to read the drive data are activated for your user account.
Details on this topic are provided in Chapter "Security settings in Startdrive" of Industrial
Cybersecurity Con󹪝guration Manual (https://support.industry.siemens.com/cs/ww/en/view/
109810578).
Description of function
The pr
ocess data in the receive direction are created automatically.
Only those telegrams available for the converter are o󹪜ered. The following information of the
displayed telegrams is displayed:
Table 8-5 Telegram structure
Telegram type PZD Display of the value Format switchover Control words
 The numbering and
arrangement of t
he
process data.
Value of the process
data (PZD)
The value of the process
data is switched to a dif‐
ferent representation
(hex, bin, dec).
List of the control
words that are trans‐
mitted in the tele‐
gram.
PROFIdrive
3, 5, 102, 105
X X X X
Torque supplementa‐
r
y teleg
ram
750
X X X X
8.9.5.2 Send direction
Ov
er
vie
w
As standard, the components and interconnections of PROFIdrive telegrams in the send
direction for the converter are displayed in this function view (e.g. 105 or 750).
You can add additional telegrams via the telegram con󹪝guration (
). The content of the
selected teleg
ram is then displayed in the "Supplementary data" area.
Requirement
• For activated user management (UMAC):
The function rights required to read the converter data are activated for your user account.
Details on this topic are provided in Chapter "Security settings in Startdrive" of Industrial
Cybersecurity Con󹪝guration Manual (
https://support.industry.siemens.com/cs/ww/en/view/
109810578).
Description of function
The
interconnections for the process data in the send direction are created automatically for the
standard and manufacturer-speci󹪝c telegrams.
Commissioning (Startdrive)
8.9Using online diagnostic functions
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
300 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
