6.10 Connecting to the 󹪝eldbus
6.10.1 Inter
face description - X150
Overview
The converter connects to the PROFINET network via ports 1 and 2 of interface X150. The
transmission rate on the interface is 10Mbit/s or 100Mbit/s.
Every PROFINET device on the network is uniquely identi󹪝ed by its PROFINET interface. For
this purpose, a PROFINET interface has the following attributes:
• A MAC address (factory default)
• An IP address
• A device name (name of the station)
Description
Table 6-13 Interface X150
X150 Pin Designation Technical speci󹪝cations
;3;3




1 TXP Transmit data +
2 TXN Transmit data -
3 RXP Receive data +
4 Reserved Reserved
5 Reserved Reserved
6 RXN Receive data -
7 Reserved Reserved
8 Reserved Reserved
LED states
For diagnos
tic purposes, the PROFINET interface X150 is equipped with a green LED and a yellow
LED.
Table 6-14 LED states of the service interface X150
LED Color Status Description
Link port - O󹪜 Missing or faulty link
Green Continuous light 10 or 100 Mbit link is available
Activity port - O󹪜 No activity
Yellow Flashing light Sending or receiving data
Connecting
6.10Connecting to the 󹪝eldbus
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 159
