Siemens SINAMICS SIMOTICS S200 PROFINET - Motor; MOTION-CONNECT 350 and 380 Cables

3.1.2 Motor
Description
The
1FL2 motor is intended for use with the S200 converter product line. The motor is available
in the 200 V variant (low or medium inertia) and the 400 V variant (low, medium, or high
inertia), and with di󹪜erent shaft heights.
Table 3-2 Motor variants
Shaft height Moments of inertia Rated power (kW) Mains supply network
SH20 Low inertia 0.05, 0.1 200V/400V
SH30 Low inertia, medium inertia 0.2, 0.4
SH40 0.75, 1.0
SH48 Medium inertia 1.0, 1.5 400V
SH52 Low inertia 1.45, 2.1
SH45 High inertia 0.4, 0.75
SH65 0.75, 1.0, 1.5, 1.75, 2.0
SH90 2.5, 3.5, 5.0, 7.0
3.1.3 MOTION-CONNECT 350 and 380 cables
Description
Pr
efabricated MOTION-CONNECT cables are used to connect the 1FL2 motor to the S200
converter product line. The cables are available in two variants:
• MOTION-CONNECT 350 standard cable, which provides a connection solution for 󹪝xed
installation applications
• MOTION-CONNECT 380 drag chain cable, which provides a connection solution for drag
chain installation applications that require a high number of bending cycles
Description
