10.4.6.8 Message word
Overview
The message word (MELDW) signals the status of the converter to the higher-level control.
Description of function
Message word (MELDW)
Converter → Control
Bit Status
00 Reserved
01 Torque utilization < threshold 2
02 |n_actual| < speed threshold 3
03 |n_actual| < speed threshold 2
04 Reserved
05 Reserved
06 No warning motor overtemperature
07 No warning converter overtemperature
08 n-target/actual deviation within tolerance
09 Reserved
10 Reserved
11 Servo enable
12 Drive ready
13 "Pulses enabled"
14 Reserved
15 Reserved
