10.4.3.5 Telegram 102
Overview
The telegram is suitable for closed-loop speed control of a drive and the control of 1 position
encoder.
Description of function
Process da‐
ta
Teleg
ram 102
Control → Converter Converter → Control
Signal Explanation Signal Explanation
PZD01 STW1 Control word1 ZSW1 Status word1
PZD02 NSOLL_B 32-bit speed setpoint NIST_B Speed actual value 32-bit
PZD03
PZD04 STW2 Control word2 ZSW2 Status word2
PZD05 MOMRED Torque reduction MELDW Message word
PZD06 G1_STW Control word for encoder 1 G1_ZSW Status word from encoder 1
PZD07 --- Not assigned G1_XIST1 Position actual value 1 from
encoder 1
PZD08 ---
PZD09 --- G1_XIST2 Position actual value 2 from
encoder 1
PZD10 ---
Functions
10.4Communication telegrams
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 337
