6.4 Connecting the mains supply
6.4.1 Inter
face description - X1
Overview
The converter connects to the mains supply via terminals L1, L2, and L3 on the interface X1.
Description
Table 6-3 Interface X1
X1 Terminal Designation Technical data
'&3
5
5
/
/
/
L1 Line phase L1/line phase L
1)
Maximum current limit: 20A
L2 Line phase L2
L3 Line phase L3/neutral N
1)
1)
For applications on the sing
le-phase mains supply network
6.4.2 Wiring
Requirement
You have assembled the converter line supply cable.
Connecting
6.4Connecting the mains supply
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
132 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
