Siemens SINAMICS SIMOTICS S200 PROFINET - Units of Measurement

• Conveyor belt
• Roller conv
eyor
For linear axes, the position of the axis is speci󹪝ed as a linear measure, for example,
millimeters (mm).
3RVLWLRQ
Rotary axis
A rot
ary axis is an axis with an in󹪝nite traversing range, for example:
• Rotary table
For rotary axes, the position of the axis is speci󹪝ed as an angular measure, for example,
degrees (°).
3RVLWLRQ
10.6.1.2 Units of measurement
Overvie
w
In addition to physical units, the converter also supports the length unit (LU) for positioning
operation.
Functions
10.6Basic positioner (EPOS)
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
370 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
