13.2.2 Replacing the motor
Requir
ement
The new motor has the same article number as the motor to be replaced. If you want to replace
the motor with another motor with a dierent article number, you must commission the
converter again after replacing the motor.
WARNING
Danger to life due to unintentional starting of the drive unit
Unintentional s
tarting of the drive unit can cause death or severe injury.
• Make sure that the drive unit cannot be started accidentally.
• Post a warning notice at the point where the switch is located.
CAUTION
Burns as a result of touching hot surfaces
In operation, the mo
tor enclosure can reach a high temperature, which can cause burns if
touched.
• Do not touch any hot surfaces.
• Allow the motor to cool down before starting any work.
• Use the appropriate personnel protection equipment, for example, gloves.
Procedure
Replacing the mo
tor with a motor with the same article number
1. Switch o the converter power supply.
2. Replace the motor.
– Disconnect the motor from the converter. You can nd detailed information in Section
"Connecting the motor (Page135)".
– Release the motor mounting screws.
– Remove the motor.
– Mount and install the new motor. You can nd detailed information in Section "Mounting
the motor (Page103)".
3. Switch the converter on.
Corrective maintenance
13.2Service and maintenance for the motor
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 603
