Display if changes have been made to the factory settings
The values enter
ed are valid.
Display for checking of the modied values
At least one of the values needs to be modied.
Mandatory t
o complete quick setup
Figure7-4 Quick setup (example)
The most important properties of the converter are congured in the q
uick setup.
Motor and encoder are directly detected during ramp-up. The data is accepted and shown in
steps "Motor" and "Encoder". The data is for information only and cannot be changed during
quick setup.
The converter creates a restore point when quick setup is started. The converter saves the
changes after every commissioning step. The converter is reset to the restore point if quick
setup is canceled.
The web server has a read-only mode for quick verication of the conguration data set.
Quick Setup Wizard
I/O conguration
• "Drive information"
The step provides information about the converter, motor, encoder and motor holding brake
being used.
The following data can be changed:
– Drive name
A specic drive name can be assigned.
• "Motor"
The data of the motor being used are displayed. It is not possible to congure another motor.
The direction of rotation of the motor can be selected.
• "Encoder"
The data of the encoder being used are displayed. Conguration is not possible.
• "Limits"
The following data can be congured:
– Limit values by making an entry in the table
The table and diagram are linked with one another.
– Device supply voltage (only available for 400 V variants)
• "I/O conguration"
In the table, a function can be assigned to an input or output of the terminal. Specied
functions can be selected. Do not assign a function to more than one input or output.
• "Summary"
The summary provides an overview of the congured settings.
Commissioning (web server)
7.4Functions and menus
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
182 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
