Page #299 background image
Procedure
Proceed as follows to call the diagnostic functions:
1. In the project tree, double-click on menu "Online&'Diagnostics".
Diagnostics and diagnostic functions are displayed in the secondary navigation and can be
called from here.
2. Select the "Online access" entry in the secondary navigation.
3. Select the network interface of your operating unit.
4. Click "Go online".
The online connection to the converter is established.
5. Click "Go o󹪠ine" in the menu bar.
The online connection to the converter is disconnected.
Overview
In the "Diagnostics" area, you can receive the following information via the secondary
navigation:
General
Active alarms and message history
Actual values
Safety Integrated functional status
PROFINET interface (X150)
A description of how you can use these functions on your converter is provided below.
Requirement
There is an online connection between the converter and the operating unit.
Diagnostic information can only be read out in the online mode.
For activated user management (UMAC):
The function rights required to read the drive data are activated for your user account.
Details on this topic are provided in Chapter "Security settings in Startdrive" of Industrial
Cybersecurity Con󹪝guration Manual (https://support.industry.siemens.com/cs/ww/en/view/
109810578).
Description of function
Y
ou call the individual diagnostic information in the secondary navigation of the diagnostics
view.
Commissioning (Startdrive)
8.9Using online diagnostic functions
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 297
