Cause: The drive does not signal a ready state after an internal switch-on command.
- DC link voltag
e is not present.
- Defective drive.
- Supply voltage incorrectly set.
Remedy: - Check the enable signals for the drive.
- Replace the driv
e.
- Check the supply voltage setting (p0210).
F07808 HF Damping Module: damping not ready
Message class: Power electronics faulted (5)
Message value: %1
Component: None
Response: OFF2
Acknowledgment: IMMEDIATELY
Cause: When switching on or in the switched-on state, the HF Damping Module does not return a ready signal.
F
ault v
alue (r0949, int
erpret hexadecimal):
1: Fault at switch-on identi󹪝ed.
2: Fault during operation identi󹪝ed.
Remedy: - Check the DRIVE-CLiQ wiring to the HF Damping Module.
- Check the 24 V suppl
y voltage.
- If required, replace the HF Damping Module.
Note:
HF Damping Module
F07810 Drive: Power unit EEPROM without rated data
Message class: Hardware/software error (1)
Message value: -
Component: Power Unit
Response: NONE
Acknowledgment: IMMEDIATELY
Cause: No rated data are stored in the power unit EEPROM.
Remedy: Replace the power unit or inform Siemens Customer Service.
F07815 Drive: Power unit has been changed
Message class: Error in the parameterization / con󹪝guration / commissioning procedure (18)
Message value: Parameter: %1
Component: Power Unit
Response: NONE
Acknowledgment: IMMEDIATELY
Cause: The code number of the actual power unit does not match the saved number. This occurs if a saved con󹪝gur
ation (SD
card,
backup 󹪝le) of a converter with another power rating is used.
Fault value only for internal Siemens diagnostics.
See also: p0201 (Power unit code number)
Remedy: - Reset to the factory settings, which corresponds to recommissioning the converter.
- Use an SD card or back
up 󹪝le with the con󹪝guration correct for the drive being used and switch-o󹪜/switch-on the drive.
- In case of doubt, before using an SD card, delete the existing con󹪝guration of the USER folder.
- For a series commissioning, only use the same converter types (order number, power class).
F07860 External fault 1
Message class: External measured value / signal state outside the permissible range (16)
