Siemens SINAMICS SIMOTICS S200 PROFINET - Page 545

Remedy: - Check the main circuit fuses.
- Check whet
her a single-phase load is distorting the line voltages.
- Detune the resonant frequency with the line inductance by using an upstream line reactor.
- Dampen the resonant frequency with the line inductance by switching over the DC link voltage compensation in the
software or increase the smoothing. However, this can have a negative impact on the torque ripple at the motor output.
- Check the motor feeder cables.
F30012 Power unit: Temperature sensor wire breakage
Message class: Power electronics faulted (5)
Message value: %1
Component: Power Unit
Response: OFF1
Acknowledgment: IMMEDIATELY
Cause: The connection to a temperature sensor in the power unit is interrupted.
F
ault v
alue (r0949, int
erpret binary):
Bit 1: Air intake
Bit 2: Inverter 1
Bit 3: Inverter 2
Bit 4: Inverter 3
Bit 5: Inverter 4
Bit 6: Inverter 5
Bit 7: Inverter 6
Bit 8: Recti󹪝er
Bit 10: Moisture ext. moisture sensor
Bit 11: Temperature ext. moisture sensor
Bit 13: Balance resistor
Bit 14: Capacitor air discharge
Bit 15: Liquid intake
Remedy: Contact Technical Support.
F30013 Power unit: Temperature sensor short-circuit
Message class: Power electronics faulted (5)
Message value: %1
Component: Power Unit
Response: OFF1
Acknowledgment: IMMEDIATELY
Cause: A temperature sensor in the power unit is short-circuited.
F
ault value (r0949, int
erpret binary):
Bit 1: Air intake
Bit 2: Inverter 1
Bit 3: Inverter 2
Bit 4: Inverter 3
Bit 5: Inverter 4
Bit 6: Inverter 5
Bit 7: Inverter 6
Bit 8: Recti󹪝er
Bit 10: Moisture ext. moisture sensor
Bit 11: Temperature ext. moisture sensor
Bit 14: Capacitor air discharge
Bit 15: Liquid intake
Remedy: Contact Technical Support.
System messages
12.3Faults and alarms
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 543
