F30022 Power unit: Monitoring U_ce
Message class: Ground fault / inter-phase short-circuit detected (7)
Message value: Fault cause: %1 bin
Component: Power Unit
Response: OFF2
Acknowledgment: POWER ON
Cause: In the power unit, the monitoring of the collector-emitter voltage (U_ce) of the semiconductor has responded.
P
ossible causes:
- F
iber-optic cable interrupted.
- The power supply for power semiconductor gating missing.
- Short-circuit at the power unit output.
- Defective semiconductor in the power unit.
Fault value (r0949, interpret binary):
Bit 0: Short-circuit in phase U
Bit 1: Short-circuit in phase V
Bit 2: Short-circuit in phase W
Bit 3: Short-circuit in phase N
See also: r0949 (Fault value)
Remedy: - Check the 󹪝ber-optic cable and if r
equired, replace.
- Check the power supply for the power semiconductor gating (24 V).
- Check the power cable connections.
- Select the defective semiconductor and replace.
F30024 Power unit: Overtemperature thermal model
Message class: Power electronics faulted (5)
Message value: Power semiconductor: %1, temperature: [0.01 degrees C] %2
Component: Power Unit
Response: OFF2
Acknowledgment: IMMEDIATELY
Cause: The temperature di󹪜er
ence betw
een the power semiconductor involved and the heat sink has exceeded the permissible
fault threshold.
- The permissible load duty cycle was not maintained.
- Insu󹪟cient cooling, fan failure.
- Overload.
- Ambient temperature too high.
- Pulse frequency too high.

Fault value (r0949, interpret hexadecimal):
yyyyxxxx hex: yyyy= Power semiconductor, xxxx = Temperature in 0.01°C
See also: r0037 (Power unit temperatures)
Remedy: - Adapt the load duty cycle.
- Check whet
her the fan is running.
- Check the fan elements.
- Check whether the ambient temperature is in the permissible range.
- Check the motor load.
- Reduce the pulse frequency if this is higher than the rated pulse frequency.
F30025 Power unit: Chip overtemperature
Message class: Power electronics faulted (5)
Message value: Power semiconductor: %1, temperature: [0.01 degrees C] %2
System messages
12.3Faults and alarms
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
546 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
