Remedy: - Carry out a POWER ON (switch-o/switch-on) f
or all components.
- Check that the encoder cables are routed in compliance with EMC.
- Check the plug connections.
- Replace encoder.
F31502 Motor encoder: Encoder with measuring gearbox without valid signals
Message class: Position/speed actual value incorrect or not available (11)
Message value: -
Component: Sensor Module Encoder 1
Response: OFF1
Acknowledgment: IMMEDIATELY
Cause: The encoder with measuring gearbox no longer provides any valid signals.
Remedy: It must be ensured that all of the encoders, with mounted measuring gearbox, provide valid actual values in operation.
F31503 Motor encoder: Position tracking cannot be reset
Message class: Position/speed actual value incorrect or not available (11)
Message value: -
Component: None
Response: OFF1
Acknowledgment: IMMEDIATELY
Cause: The position tracking for the measuring gearbox cannot be reset.
Remedy: The fault should be resolved as follows:
- Select commis
sioning.
- Reset t
he position tracking as follows (p0411.2 = 1).
- Deselect commissioning.
The fault should then be acknowledged and the absolute encoder adjusted.
A31700 Motor encoder: Functional safety monitoring initiated
Message class: Safety monitoring channel has identied an error (10)
Mes
sage value: Fault cause: %1 bin
Component: Sensor Module Encoder 1
Response: NONE
Acknowledgment: NONE
Cause: Functional safety was activated. Self test of the DRIVE-CLiQ encoder has detected a fault.
Alarm value (r2124, int
erpre
t binary):
Bit x = 1: Eectivity test x unsuccessful.
Remedy: Replace encoder.
F31802 Motor encoder: Time slice overo
w
Message class: Hardware/software error (1)
Message value: %1
Component: Sensor Module Encoder 1
Response: ENCODER
Acknowledgment: IMMEDIATELY
System messages
12.3Faults and alarms
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 579
