• Scenario 1: A driv
e password is congured in the source converter. On the other hand,
function "Drive data encryption" had been previously de-activated in the target converter.
1
2 3
$SFBUFCBDLVQMF
3FTUPSFESJWFEBUB
%SJWFQBTTXPSEGPSDPOWFSUFS"
$POWFSUFS"
$POWFSUFS#
$POWFSUFS#
୫3FQMBDFDPOWFSUFS"
ࡒ#
– Click on "Restore".
A dialog to enter the password opens.
– Enter the drive password of the source converter.
The drive data are loaded into the converter from the backup le.
As a consequence, the status of the settings at the instant of the backup are restored.
Function "Drive data encryption" is activated. The drive password of the source converter
is transferred to the target converter.
• Scenario 2: The same drive password is congured in the source and target converters.
1 2 3
$SFBUFCBDLVQMF3FTUPSFESJWFEBUB
%SJWFQBTTXPSEGPSDPOWFSUFST"BOE#
$POWFSUFS"$POWFSUFS#$POWFSUFS#
୫3FQMBDFDPOWFSUFS"
ࡒ#
– Click on "Restore".
A dialog to enter t
he password opens.
– Enter the drive password of the target converter.
A dialog to enter the password opens.
Corrective maintenance
13.1Service and maintenance for the converter
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 597
