MOTION-CONNECT 350 and 380 cables Connectors
Type Article
number
6FX3☐02-
1)
Applicable
1FL2 mo
tor
Cr
oss-section for conductors
(mm
2
)
Drive
side
6FX2003
-
Motor
side
6FX2003-
Power cable (with brake conduc‐
tors)
5DK32-
☐☐☐☐
SH48
SH52
4×0.75+2×0.38
(4×18AWG+2×22A
WG)
-

0LL63
Power cable (without brake con‐
ductors)
5CK32-
☐☐☐☐
4×0.75 (4×18AWG)
5CL01-
☐☐☐☐
SH45
SH65
SH90
4×0.75 (4×18AWG) 0LL13
5CL02-
☐☐☐☐
4×1.5 (4×16AWG)
5CL12-
☐☐☐☐
4×2.5 (4×14AWG)
Encoder cable

2XB11-
☐☐☐☐
SH48
SH52
• Cable length ≤15m:
3×2×0.25
(3×2×24AWG)
•
Cable length 20m or 30m:
2×2×0.25+2×0.38
(2×2×24AWG+2×22AWG)
0DE61

0DB63
2XB12-
☐☐☐☐
SH45
SH65
SH90
0DB13
Brake cable
5BL03-
☐☐☐☐
2×0.75 (2×18AWG) - 0LL53
1)
The last four digits (☐☐☐☐) in the cable article number de󹪝ne the cable length corresponding to the length code: 1AD0 =
3 m, 1AF0 = 5 m, 1AH0 = 7 m, 1BA0
= 10 m, 1BF0 = 15 m, 1CA0 = 20 m, 1DA0 = 30 m.
2)
The conductors for the motor holding brake are integrated in the MOTION-CONNECT power cable.
If you prefer to use non-Siemens cables, Siemens provides the following connectors for you
to assemble your own cables.
Note that Siemens does not provide any guarantee or warranty regarding the functionality,
reliability or quality of non‑Siemens cables used with the S200 servo drive system, and is not
responsible for device (e.g. motor and converter) damages due to the use of non-Siemens
cables.
Description
3.4Accessories
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 61
