Table 14-21 Vibration values for motors with high inertia
Vibration velocity V
rms
t
o
ISO10816
Vibr
ation acceleration a
peak
axial Vibration acceleration a
peak
ra‐
dial
Max. 4.5mm/s 25m/s
2
50m/s
2
To evaluate the vibration velocity, the measuring equipment must meet the requirements of
ISO2954.
Select the measuring locations accor
ding to ISO10816-1, Section 3.2. See the illustration
below for more information on the measuring points.






① End shield DE radial ④ End shield NDE radial
② End shield DE radial ⑤ End shield NDE axial
③ End shield DE axial ⑥ End shield NDE radial
The vibration acceleration is evaluated in the frequency range from 10Hzto2000Hz. The
maximum peak in the measurement time r
ange is considered.
The vibration values must not exceed the speci󹪝ed limits at any measuring location.
14.2.9 Shaft extension
Technical data
The motors are supplied with cylindrical shaft extensions. The shaft extension usually has a
centering thread according to DIN332, form DR.
Optionally, a shaft extension with key slot and feather key is available.
Technical data
14.2Technical data of the motor
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
632 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
