14.2.13.2 Technical data of the 1FL2 holding brake
Technical data
Table 14-27 Technical data of the holding brake
Motor type Holding tor‐
q
ue
Dynamic
braking tor‐
q
ue
Opening
time
Closing time Maximum
permissible
single oper‐
ating ener‐
gy
1)
Total operat‐
ing energy
(service life)
Holding
current
M
4
/ Nm M
1m
/ Nm t
open_f
/ ms t
close_f
/ ms W
max
/ J W
tot
/ kJ I
h
/ A
P
ermanent-magnet brake
1FL2☐05 8 5 90 25 142 284 < 1 A
Spring-loaded brake
1FL2102 0.32 - 35 10 1 2 < 1 A
1FL2☐03 1.3 - 60 10 10 20 < 1 A
1FL2104
1FL2204
3.3 - 110 30 43 86 < 1 A
1FL2304 3.5 - 60 45 140 280 < 2 A
1FL2306 12 180 60 600 1200 < 2 A
1FL2310 30 - 220 115 1100 2200 < 2 A
1)
Maximum of three consecutiv
e EMERGENCY STOP procedures. Maximum25% of all EMERGENCY STOP procedures as high-
energy stops with W
max
.
Holding torque M
4
: The holding torque M
4
is the highest permissible torque for the closed
brake in steady-state operation without slip (holding function when motor is at standstill).
The data applies to the state at operating temperature (120°C).
Dynamic braking torque M
1m
: The dynamic braking torque M
1m
is the smallest mean
dynamic braking torque that can occur for an EMERGENCY STOP.
Opening time t
o
and closing time t
cl
: The delay times that occur when switching the
brake t
o
and t
cl
are saved in the motor and are automatically taken into consideration. After
activation of the holding brake (opening), the speed/velocity setpoint remains at "Zero"
during the opening time t
o
. The speed/velocity setpoint is only enabled after the opening
time t
o
has elapsed. After OFF1 or OFF3 and activation of the holding brake (closing), the
motor still remains in closed-loop control with speed/velocity setpoint "Zero" during closing
time t
cl
. The pulses are only deleted after this.
Maximum permissible single operating energy W
max
: The maximum permissible single
operating energy of an individual EMERGENCY STOP operation. After an EMERGENCY STOP
with the maximum single operating energy, allow a cooling time of at least threeminutes
before you operate the motor again.
Total operating energy (service life) W
total
: The total operating energy is the sum of the
single operating energy (operating energy for each EMERGENCY STOP procedure). If you
exceed the total operating energy, problem-free functioning of the brake can no longer be
guaranteed.
Technical data
14.2Technical data of the motor
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 643
