c2053[0...27] PROFIdrive PZD send word
 Data type: Unsigned16 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Send direction
Unit: -
Description: Displays the PZD (actual values) in the word format that are sent to the 󹪝eldbus controller.
Inde
x: [0] = PZD 1
[1] = PZD 2
[2] = PZD 3
[3] = PZD 4
[4] = PZD 5
[5] = PZD 6
[6] = PZD 7
[7] = PZD 8
[8] = PZD 9
[9] = PZD 10
[10] = PZD 11
[11] = PZD 12
[12] = PZD 13
[13] = PZD 14
[14] = PZD 15
[15] = PZD 16
[16] = PZD 17
[17] = PZD 18
[18] = PZD 19
[19] = PZD 20
[20] = PZD 21
[21] = PZD 22
[22] = PZD 23
[23] = PZD 24
[24] = PZD 25
[25] = PZD 26
[26] = PZD 27
[27] = PZD 28
Dependency: See also: c2063
r2060[0...20] PROFIdrive PZD receive double word
 Data type: Integer32 V
isible in: Standard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Receive direction
Unit: -
Description: Displays the PZD (setpoints) in the double word format received from the 󹪝eldbus controller.
