Description
When operated with rated power, the converter generates the following typical current
harmonics:
Table 4-4 Typical harmonic currents of the converter, 1 AC 200 V
200 V convert‐
er
Typical harmonic current (A) at U
k
4%
5th 7th 11th 13th 17th 19th 23rd 25th THC
FSA 0.57 0.42 0.16 0.07 0.10 0.10 0.07 0.04 1.05
FSB 0.55 0.44 0.22 0.11 0.05 0.06 0.05 0.02 1.04
FSC 0.19 0.18 0.15 0.10 0.04 0.03 0.01 0.02 0.43
THC = Total Harmonic Current: sum of all harmonic currents
T
able 4-5
T
ypical harmonic currents of the converter, 3 AC 200 V
200 V convert‐
er
Typical harmonic current (A) at U
k
4%
5th 7th 11th 13th 17th 19th 23rd 25th THC
FSA 0.18 0.13 0.08 0.05 0.04 0.02 0.02 0.02 0.26
FSB 0.94 0.66 0.19 0.08 0.15 0.13 0.07 0.07 1.2
FSC 2.37 1.64 0.40 0.22 0.34 0.25 0.10 0.13 2.97
THC = Total Harmonic Current: sum of all harmonic currents
Table 4-6 T
ypical harmonic currents of the converter, 3 AC 400 V
400 V converter Typical harmonic current (A) at U
k
4%
5th 7th 11th 13th 17th 19th 23rd 25th THC
FSA 0.38 0.31 0.24 0.29 0.34 0.29 0.30 0.29 1.03
FSB 1.11 0.79 0.74 0.87 0.80 0.72 0.75 0.74 2.56
FSC 3.05 2.08 2.11 2.40 2.10 1.80 1.66 1.47 6.17
FSD 5.69 3.29 4.42 4.58 2.81 2.47 1.86 1.26 10.27
THC = Total Harmonic Current: sum of all harmonic currents
