Simplex 4005 Programming Instructions

5-22
Pt. TYPE: RVISUAL Description: Visual (on until reset)
Operates on General Alarm
Circuit Status LCD Readout (2
nd
line) LED
On Visual ON
Off Visual OFF
Visual CODING
Disabled TBL Visual TROUBLE T
Off Auto TBL Visual TROUBLE T
Detailed Description: Used on visual alarm device circuits that must be ON
until the system reset key is pressed (not supervised).
Figure 5-58. RVISUAL Point Type
Pt. TYPE: CODED Description: Coded Relay (PNIS)(normally off)
Operates on General Alarm
Circuit Status LCD Readout (2
nd
line) LED
On Coded Relay ON
Off Coded Relay OFF
Coded Relay CODING
Disabled TBL Coded Relay TROUBLE T
Off Auto TBL Coded Relay TROUBLE T
Detailed Description: Relay will track any PNIS code zone.
NOTE: PNIS is not available with the 4005 at this time.
Figure 5-59. CODED Point Type
Pt. TYPE: SWATER Description: Waterflow Relay (on until silence)
Operates on General Alarm
Circuit Status LCD Readout (2
nd
line) LED
On WaterFlow Relay ON
Off WaterFlow Relay OFF
WaterFlow Relay CODING
Disabled TBL WaterFlow Relay TROUBLE T
Off Auto TBL WaterFlow Relay TROUBLE T
Detailed Description: Used in applications where a waterflow signal circuit is
required which will remain activated until the silence key is pressed. Activated
from a zone with the point type WATER.
Figure 5-60. SWATER Point Type
Continued on next page
Point Type Messages for Auxiliary Relay Points, Continued
Auxiliary Relay Points
(continued)
