Simplex 4005 Programming Instructions

5-23
Pt. TYPE: RWATER Description: Waterflow Relay (on until reset)
Operates on General Alarm
Circuit Status LCD Readout (2
nd
line) LED
On WaterFlow Relay ON
Off WaterFlow Relay OFF
WaterFlow Relay CODING
Disabled TBL WaterFlow Relay TROUBLE T
Off Auto TBL WaterFlow Relay TROUBLE T
Detailed Description: Used in applications where a waterflow signal circuit is
required which will remain activated until the reset key is pressed. Activated
from a zone with the point type WATER.
Figure 5-61. RWATER Point Type
Pt. TYPE: SUPV Description: Sprinkler Supervisory Relay (on
until acknowledged)
Circuit Status LCD Readout (2
nd
line) LED
On Supervisory Relay ON
Off Supervisory Relay OFF
Supervisory Relay CODING
Disabled TBL Supervisory Relay TROUBLE T
Off Auto TBL Supervisory Relay TROUBLE T
Detailed Description: used in applications where a Supervisory signal circuit is
required which will remain ON until acknowledged.
Figure 5-62. SUPV Point Type
Pt. TYPE: RELAY Description: Generic Relay (no default
operation)
Circuit Status LCD Readout (2
nd
line) LED
On Auxiliary Relay ON
Off Auxiliary Relay OFF
Auxiliary Relay CODING
Disabled TBL Auxiliary Relay TROUBLE T
Off Auto TBL Auxiliary Relay TROUBLE T
Detailed Description: Used for all relay applications that are not defined by a
specific point type.
Figure 5-63. RELAY Point Type
Continued on next page
Point Type Messages for Auxiliary Relay Points, Continued
Auxiliary Relay Points
(continued)
Technical Manuals Online! - http://www.tech-man.com

Simplex 4005 Specifications

General

Brand	Simplex
Power Supply	24 VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Compatibility	Compatible with Simplex fire alarm control panels
