Library of Function Blocks
4.81
II. AUTO MANUAL KEYS
The actuation sequence for the A/M stations is established by the parameters
CMV1 through CMV4.
These parameters are used for both analog (increase and decrease) and digital (Automatic/Manual)
signals.
The blocks corresponding numbers are given in Table 4.36.2.
CMV BLOCK No. BLOCK NAME
0 BLK035
1 BLK036
2 BLK037
3 BLK038
Function 08
A/M Station
Table 4.36.2 - A/M Block Corresponding numbers for CMV Parameters
III. LOCAL/REMOTE KEYS
The actuation sequence of the digital (Local/Remote) signals of the L/R SP Selector blocks is
established by the parameters CLR1 through CLR4. The Table 4.36.3 shows numbers related to the
blocks.
IV. DIGITAL VARIABLES
Up to eight digital signals can be accessed via the communication bus. These variables are
available at the gates 161 through 168, and can be used by any block of the configuration.
Remember that the digital actuation of the L/R and A/M front panel keys is done through parameters
CLRx and CMVx, respectively.
Representation of digital variables is in bit form.
V. ANALOG VARIABLES
Up to two analog variables can be received in this group. They are available at the outputs 169 and
170, and can be used by any block of the configuration.
Representation is in word form.
VI. ALARM LIMITS
The commands for actuation on the individual alarm limits can be received in this group, in the
sequence determined in the parameters AL01 through AL20. The selection range of these
parameters is from 0 to 20, as shown in Table 4.36.4.
AL BLOCK No. BLOCK NAME BLOCK IDENTIFICATION
0 -
Interrupts the Scan
-
1 BLK039
2 BLK040
3 BLK041
4 BLK042
Function 09 Advanced PID Control
Parameter
AMXD
5 BLK077
6 BLK077
7 BLK078
8 BLK078
9 BLK079
10 BLK079
11 BLK080
12 BLK080
Function 22 Double Alarm
Parameters
ARG1;
ARG2
13 BLK081
14 BLK081
15 BLK082
16 BLK082
17 BLK083
18 BLK083
19 BLK084
20 BLK084
Function 23
Limiter with
Alarm
Parameters
A-BL;
A-BH
Table 4.36.4 - Alarm Corresponding numbers for AL Parameters
