SMAR CD600 Plus - Function 17 - Polynomial (Pol); Operation

Library of Function Blocks
4.47
Function 17 - Polynomial (POL)
Operation
This block executes mathematical operations established by the functions 0, 1 or 2, as shown in the
Figure. The function is selected in parameter
CTYP:
CTYP = 0 A-B difference.
CTYP = 1 4th-order polynomial.
CTYP = 2 3-input sum.
Inputs
A, B, C and coefficient K
0
are interpreted as percentages, while coefficients K
1
to K
4
are real
numbers. Inputs and output may range from -102.00 to +102.00%.
Inputs are standardized as follows:
100
%
100
%
100
%
CInput
C
BInput
B
Input
AInput
A
=
=
=
The output signal will be the result of the equation multiplied by 100%.
EXAMPLE 1:
Input
A = 80%
Input
B = 55%
Input
C = 10%
K
0
= 30; K
1
= 1; K
2
= 0.5; K
3
= 2; K
4
= 0.1
%29.71
1
%25
25.055.080.0
0
10.0
100
10
;55.0
100
55
;8.0
100
80
=
=
=
=−=−=
=
======
Output
30 +]100 0.10 + ) (0.25 1 +
) (0.25
2
0.5 +
(0.25)
3
2 +
) (0.25 0.1 [
4
= Output
CTYPFor
Output
BAOutput
CTYPFor
CBA
