CD600 Plus - User's Manual
4.76
Function 33 - Constants (K)
Operation
This block generates a constant value to be used at any point of the configuration. As the same
constant may be used in more than one loop, this block must be configured in the General Loop
(Loop G). It has ten adjustable constants, each one being available at one output. These outputs
can be connected to blocks located in any loop.
K01 151
K02 152
K03 153
K04 154
K05 155
K06 156
K07 157
K08 158
K09 159
K10 160
This block should be used when it is necessary to generate a constant value for the other blocks of
the configuration. An example of this type of application is a process which demands that the
controller output should go to 10% when a digital signal changes from Low to high logic level.
The constant value 10% can be adjusted in
AK01 of this block and its output (151) connected to the
input
B of a block of the Function 08 - Automatic/Manual Station. The digital signal is connected
to input
C of the A/M block.
TYPE MNEM DESCRIPTION RANGE DEFAULT
P AK01 Constant K01 -300.00 to +300.00% 10.00%
P AK02 Constant K02 -300.00 to +300.00% 20.00%
P AK03 Constant K03 -300.00 to +300.00% 30.00%
P AK04 Constant K04 -300.00 to +300.00% 40.00%
P AK05 Constant K05 -300.00 to +300.00% 50.00%
P AK06 Constant K06 -300.00 to +300.00% 60.00%
P AK07 Constant K07 -300.00 to +300.00% 70.00%
P AK08 Constant K08 -300.00 to +300.00% 80.00%
P AK09 Constant K09 -300.00 to +300.00% 90.00%
P AK10 Constant K10 -300.00 to +300.00% 100.00%
Number of Bytes per Type of Parameter: A = 20 C = 0 L = 0
