Function 35 - Scan/Actuation Of The Parameters PID (PRM)
Operation
This block allows the actuation and reading of the parameters K
P
, T
R
, T
D
and Bias of the PID and
advanced PID blocks through the communication bus.
The order of the information in the scan communication buffer is also the order of actuation. It will be
determined by the parameters CTR1 through CTR8, with the values from 0 to 8, each number
corresponding to a block, according to the Table 4.35.1.
0
Interrupts the Scan
1 BLK039
2 BLK040
3 BLK041
4 BLK042
Function 09
Advanced PID
5 BLK043
6 BLK044
7 BLK045
8 BLK046
Function 10
Simple PID
Table 4.35.1 - PID Block Corresponding numbers
If a parameter is found with the DEFAULT value ("0"), the scan is interrupted.
TYPE MNEM DESCRIPTION RANGE DEFAULT
P CBID User free identification number 0 - 100 0
P CTR1 Number of 1st PID 0 - 8 0
P CTR2 Number of 2nd PID 0 - 8 0
P CTR3 Number of 3rd PID 0 - 8 0
P CTR4 Number of 4th PID 0 - 8 0
P CTR5 Number of 5th PID 0 - 8 0
P CTR6 Number of 6th PID 0 - 8 0
P CTR7 Number of 7th PID 0 - 8 0
P CTR8 Number of 8th PID 0 - 8 0
Number of Bytes per Type of Parameter: A = 0 C = 18 L = 0
