CD600 Plus - User's Manual
4.78
IV. TOTALIZATIONS
The eight totalizations corresponding to the blocks of Function 18 - "Totalization" and Function
19 - Pulse Input
are allocated in this group.
It is not necessary to list the totalization parameters. They will be included in the digital
communication automatically, in the same order they appear in the configuration.
The Pulse Input block has two totalization registers. The totalization register occupies 4 bytes.
V. DIGITAL INPUTS AND OUTPUTS
The status of the four inputs and the eight digital outputs, in a fixed order, are located in this group.
They are represented in bit form, and are not necessary to list.
TYPE MNEM DESCRIPTION RANGE DEFAULT
I LI01 Address of analog block output 0
I LI02 Address of analog block output 0
I LI03 Address of analog block output 0
I LI04 Address of analog block output 0
I LI05 Address of analog block output 0
I LI06 Address of analog block output 0
I LI07 Address of analog block output 0
I LI08 Address of analog block output 0
I LI09 Address of analog block output 0
I LI10 Address of analog block output 0
I LI11 Address of analog block output 0
I LI12 Address of analog block output 0
I LI13 Address of analog block output 0
I LI14 Address of analog block output 0
I LI15 Address of analog block output 0
I LI16 Address of analog block output 0
I LI17 Address of analog block output 0
I LI18 Address of analog block output 0
I LI19 Address of analog block output 0
I LI20 Address of analog block output 0
I LI21 Address of analog block output 0
I LI22 Address of analog block output 0
I LI23 Address of analog block output 0
I LI24 Address of analog block output 0
I LI25 Address of analog block output 0
I LI26 Address of analog block output 0
I LI27 Address of analog block output 0
I LI28 Address of analog block output 0
I LI29 Address of analog block output 0
I LI30 Address of analog block output 0
I LI31 Address of analog block output 0
I LI32 Address of analog block output 0
I LI33 Address of logic level block output 0
I LI34 Address of logic level block output 0
I LI35 Address of logic level block output 0
I LI36 Address of logic level block output 0
I LI37 Address of logic level block output 0
I LI38 Address of logic level block output 0
I LI39 Address of logic level block output 0
I LI40 Address of logic level block output 0
I CBID User free identification number
Addresses
0 to 170/225 to 240
Addresses
0 to 170/225 to 240
0
Number of Bytes per Type of Parameter: A = 0 C = 2 L = 80
