SMAR CD600 Plus - Page 123

Technical Specifications
8.3
1
2
3
4
5
Figure 8.2. Communication Controller
CD600
TERMINAL
24V 5
AI1 1
a) 2 WIRE TRANSMITTER
TRANSMITTER
ANALOG INPUTS
NOTE: IF THE ANALOG INPUT IS USED AS CURRENT INPUT, IT IS NECESSARY TO INSERT
A 250 OHM SHUNT RESISTOR IN THE SHUNT RESISTOR TERMINAL.
CD600
TERMINAL
GNDA
10
b) 4- WIRE TRANSMITTER
TRANSMITTER
POWER SUPPLY
AI1 1
CD600
TERMINAL
VOI 6
GNDA
10
RECEPTOR
a) VOLTAGE
+
ANALOG OUTPUTS
CD600
TERMINAL
GNDA
33
b) CURRENT
ACTUATOR
CO1 37
+
DIGITAL INPUTS
CD600
PI1 11
GNDA
28
a) CONTACT
VEXT2
15
24 VDC
CD600
PI1 11
GNDA
28
a) VOLTAGE
VEXT2
15
24 VDC
3 to 24V
DIGITAL OUTPUTS (OPEN COLLECTOR)
DO1 16
24V 5
VEXT 20
GND 23
I MAX<400mA
LOAD
DO 16
LOAD (RELAY)
I MAX<400mA
VCE<35 VDC
VEXT 20
GND 23
CD600
TERMINAL
CD600
TERMINAL
a) EXTERNAL SOURCE b) INTERNAL SOURCE
Figure 8.3. Cabling Diagram for Inputs and Outputs
