CD600 Plus - User's Manual
4.12
In the above configuration, when in Local mode, actuation is performed in the register of Block 031
and, in Remote mode, in Block 099, although the visualized output is that of Block 031.
TYPE MNEM DESCRIPTION RANGE DEFAULT
I LIA Input A - Variable to Remote Mode 0
I LIB Input B - Variable to Local Mode 0
I LIC Input C - Forces Local Mode
Addresses
0 to 170 / 225 to 240
0
I CLKR Locks switch CH1 in: 0-No Lock/1-Remote/2-Local 2
I CTON Starting condition after power failure
0 - Last mode
1 – Local
2 – Remote
0
P ASLW
Maximum rate-of-change in Remote
mode
1.00 - 200.00%/s 200.00%/s
P ASPD Register actuation speed 0.00 - 200.00%/s 10.00%/s
P ALOW Register lower limit -102.00 to +102.00% 0.00%
P AUPP Register upper limit -102.00 to +102.00% 100.00%
Number of Bytes per Type of Parameter: A = 8 C = 4 L = 6
