Library of Function Blocks
4.25
TYPE MNEM DESCRIPTION RANGE DEFAULT
P CLIN Curve for the Adaptative Gain
0-X=Y
1→8/Curves 1 →8
9-Curves 1 and 2
10-Curves 3 and 4
11-Curves 5 and 6
12-Curves 7 and 8
0
I CAAD Adaptative Gain Action 0- Not Used/ 1-PID/ 2-PI/3-P/4-I/5-D 0
P CARL Antireset-Windup lower limit -2.00 to +50.00% 0.00%
P CARU Antireset-Windup upper limit +50.00 to +102.00% 100.00%
I CFRT Error alarm indication on front panel
0-No/1-Yes
2-Yes With Auto Ack.
0
P Akp Proportional Gain 0.00 - 100.00 0.30
R Atr Integral time (min./repetition) 0.01 - 1000.0 10.000
R Atd Derivative constant (min.) 0.00 - 100.00 0
P ABIA Bias -100.00 - 100.00% 0.00
P AMXD Maximum deviation without alarm (%) 0.00 - 100.00% 0.00%
P ATOD Maximum time for deviation alarm (min.)
0.01 - 200.00 min.
0.00 - No Alarm
0.00 min
Number of Bytes per Type of Parameter: A = 16 C = 26 L = 10
