CD600 Plus - User's Manual
4.54
TYPE MNEM DESCRIPTION RANGE DEFAULT
I LIA Input A (Density) 0
I LIB Input B (Counting decrement) 0
I LIC Input C (Resets totalizer)
Addresses
0 to 170 / 225 to 240
0
I CTYP Definition of the block function
0 – Digital
1 - Inverted Digital
2 – Totalizer
0
I CMFR Turbine maximum frequency
0
→f<500 Hz
1
→f>500 Hz
1
R AFSV Turbine Factor 0 to 10 E 37 1.0000
R AFTR Adjusting factor (K-factor) 0 to 10 E 37 1.0000
R A-FE Factor FE (totalization unit) 0 to 10 E 37 1.0000
R AZDN Density at 0% 0 to 10 E 37 0.2000
R AMDN Density at 100% 0 to 10 E 37 0.4000
R AMFL Maximum Flow rate in engineering units 0 to 10 E 37 250.00
I APLS Number of pulses per cycle 0-32000 32
Number of Bytes per Type of Parameter: A = 26 C = 4 L = 6
