Library of Function Blocks
4.57
TYPE MNEM DESCRIPTION RANGE DEFAULT
I LIA Input A (input to comparator) 0
I LIB Input B (stall time) 0
I LIC Input C (Pause) 0
I LID Input D (Reset)
Addresses
0 to 170 / 225 to 240
0
I CLIN Curve(s) used to determine the time pattern
0 - None (output - 0)
1 to 8 -Curves 1 to 8
9 - Curves 1 and 2
10 - Curves 3 and 4
11 - Curves 5 and 6
12 - Curves 7 and 8
13 - Curves 1 to 4
14 - Curves 5 to 8
15 - Curves 1 to 6
16 - Curves 1 to 8
0
I CUNI Time unit
0 – Minutes
1 - Hours
0
P CTME Time corresponding to 100% 0.00 - 300.00 60.00
P ASPD Time register Actuation Speed 0.00%/s - 200.00%/s 10.00%/s
P ALOW Lower time register limit -102.00% to +102.00% 0.00%
P AUPP Upper time register limit -102.00% to +102.00% 100.00%
P ADEV Deviation (in modules) 0.00 - 100.00% 100.00%
Number of Bytes per Type of Parameter: A = 8 C = 6 L = 8
