Spectra Precision Focus 30 Service Manual

Chapter 4
Troubleshooting
P/N 79000035_SM, Version 1.5 4 - 21 Focus 30/35 Service Manual
information of all sensor can be shown on F2 panel in Show system state. As an active part the
onboard Diagnostics in
Run system diag. can be performed to test the instrument more in detail. The
selftest results will be shown as
Ok status or error/event message codes. The messages/codes are
displayed in combination of numerics 1-6 and characters A-D. The results are stored in a logfile,
which can be read out and sent to the Service provider.
The System Monitor information is valid for a running instrument only and can be stored in *.fsmx
file. After restart of the instrument the messages and counters will be reset.
Performance
Item Performance Action Notes
1 Enter Service menu A. Go to Control Unit
F2
Main Menu.
B. Hold
Enter for 3
seconds.
C. Press arrow buttons
to reach the
Service
Menu.
D. Enter Service Menu.
2 Enter System
diagnostics
A. Press arrow buttons
to reach the
System
diagnostics.
B. Enter
System
diagnostics.
C.
Show system state
and
Run system diag.
are now accessible.
Radio Parameter
Level Bubble
Instrument Details
Main Menu
Service Menu
Exit
Run system diag.
System diagnostics
Show system state
