14215700-IG, Edition 8.0
April 2018, Original document
174
Redundant System Configuration
Note:
Not relevant to the Spectralink IP-DECT Server 200/400.
This section describes the redundancy feature in the Spectralink IP-DECT Server 6500. You will find
a description of how to design, configure and administer a redundant Spectralink IP-DECT Server
6500 solution including a master and a backup server.
The redundancy feature of the Spectralink IP-DECT Server 6500 solution allows adding a backup
server to the system, offering both better availability and better performance due to load balancing.
By adding a backup server, the most critical failure point of the system is eliminated, allowing the sys-
tem to continue running and provide service to the users, even when a server fails. Any active calls or
sessions handled by the failed component will however be lost.
The redundancy feature is designed to be as non-intrusive as possible. Except for a few simple
redundancy options, configuration and administration of a redundant solution is not different from a
single server solution. All configurations are executed on the master server, and everything is presen-
ted in the same familiar menus. Configuration data and statistics are automatically propagated
between all the Spectralink IP-DECT Server 6500 entities, e.g. base stations, media resources and
server.
Note:
If a third party application is connected to the Spectralink IP-DECT Server 6500, e.g. a
messaging application or a nurse call application, this application must connect to the
master Spectralink IP-DECT Server 6500.
In case of a failure in the master server, the application will not be able to communicate
with the handsets unless the application is designed for redundancy.
This is further described in the XML-RPC SDK document. To obtain this document go to
this site:
http://www.spectralink.com/partners/app-developers/aims-application-form and fill out
an application form.
Firmware Compatibility (Redundancy)
For using a redundant server solution, it is required that the backup Spectralink IP-DECT Server has
the same firmware revision and licensed features as the master Spectralink IP-DECT Server to be
able to connect to the master.
In case a backup server tries to connect with a different firmware version or other licensed features
than the master server, an error message will be logged and the backup server will be rejected.
For latest SW available, please go to http://support.spectralink.com/.
Note:
Provisioning of server firmware it not possible in a redundant setup.
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide
