14215700-IG, Edition 8.0
April 2018, Original document
185
Configuring a Master Spectralink IP-DECT Server 6500
The master Spectralink IP-DECT Server 6500 must be configured as a normal single server solution
with base stations, media resources and users as ānormalā and it must be verified that the desired
functionality is working before enabling the redundancy feature, and the backup Spectralink IP-
DECT Server 6500 is added.
1. Ensure that the Redundancy License is installed, and that the master server is configured cor-
rectly.
License installation requires reboot of system.
2. Click Configuration, and then click Redundancy.
3. On the Redundancy Configuration page, enter the following data:
Field Setting
Redundancy Configuration - Node type
Single If selected, this will disable redundancy and configure for
stand alone (normal single server solution).
Select Single, if this device is to be a normal single
server solution.
Master If enabled, this will enable redundancy and configure the
device as master server. The system will be controlled by
this device.
Select Master, if this device is to be the master server.
Slave If enabled, this will enable redundancy and configure the
device as backup (slave) server. The device will be con-
trolled by a master server.
Select Slave, if this device is to be the backup server.
Redundancy Configuration - Peer node
Address If master server, enter the fixed IP address or hostname
for the backup Spectralink IP-DECT Server 6500.
If backup server, enter the fixed IP address or hostname
for the master Spectralink IP-DECT Server 6500.
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide
