Field Setting
Phonebook Configuration - Disabled
Disabled As default, phone book configuration is disabled.
You can configure the server to retrieve phone book data using
LDAP server or by import of phone book data from a CSV file.
Phonebook Configuration - Imported CSV file
Imported CSV file Enable this if you want to import phone book data from CSV
file.
Import Browse for the CSV file to import.
Note: The CSV file must contain correct format. For more
information, see "Parameter Overview" on page223.
Encoding Select the correct encoding for the CSV file. You can choose
between UTF-8, ISO/IEC 8859-1 or Windows-1252.
Note: The encoding depends on the software that was used to
generate the CSV file. If you use Microsoft Windows, you will
probably select Windows-1252.
Number fields Enter the indexes of the columns containing dialable numbers.
Phonebook Configuration - LDAP
LDAP Enable this if you want to configure the server to retrieve phone
book data using LDAP server.
For an example of LDAP configuation, see "Parameter Over-
view" on page223.
URI Enter the URI of the LDAP server.
E.g. ldap://example.com
Bind user (Optional) Enter the username used for authentication against LDAP.
Note: It might be necessary to specify the path for username
(DOMAIN\username).
E.g. CN=Manager, DC=example, DC=com.
Bind password (Optional) Enter the Bind user’s password.
Base (Optional) Enter the base path where the users are located in the LDAP
structure.
E.g. DC=example, DC=com.
