14215700-IG, Edition 8.0
April 2018, Original document
101
Configuring SIP and IP-PBX Settings
You can configure general SIP settings, authentication information, DTMF signalling, message wait-
ing indication and media for the IP-PBX through the web based Administration Page.
This section describes how to configure general SIP settings and register for SIP.
For more information about IP-PBX specific settings, see the relevant Interoperability Guides.
To Configure SIP Settings
To configure SIP settings from the web based Administration Page:
1. Click Configuration, and then click SIP.
2. On the SIP Configuration page, enter the following data:
Field Setting
SIP Configuration - General
Local port Enter the local port number.
The local port is the port on which the Spectralink IP-
DECT Server listens for incoming SIP-signalling.
The default local port number is 5060.
Transport Transport mechanism used for SIP messages.
Possible values: UDP, TCP or TLS.
Note: If TLS is used as SIP Transport Method, it is neces-
sary to import host certificate and CA certificates into the
server. For more information, see "Configuring Cer-
tificates" on page116.
DNS method Used for looking up the destination of SIP messages.
Possible values: A records or DNS SRV.
Default domain Used for SIP registration. Enter the name of the domain.
Note: If no user specific domain is configured under a
specific user, the handsets registered on the Spectralink
IP-DECT Server will use the default domain as the
domain part of the SIP URI;
e.g. John Doe <sip:1234@example.org>
If only one SIP PBX is used and no domain is available,
enter the IP address of PBX here.
Register each endpoint on sep-
arate port (Optional)
If enabled, separate local ports for each endpoint are
used, instead of the global local port.
Spectralink IP-DECT Server 200/400/6500 Installation and Configuration Guide
