Field Setting
SIP Configuration - Proxies
Proxies (Optional) Priority: The priority for using this proxy.
Possible Value 1-4.
Weight: The weight for using this proxy if more proxies have
the same priority.
Possible value 1 - 65.000 higher weight gives priority.
Default value: 100
URI: The URI or IP address of the proxy
SIP Configuration - Authentication
Default user (Optional) Default user name used for SIP authentication.
Note: If no handset specific authentication user name/-
password is configured, handsets registered on theSpec-
tralink IP-DECT/DECT Server will use the default user
name/password.
Default password (Optional) Enter password.
Realm (Optional) The realm presented by the proxy when requesting authen-
tication. If this field is non-empty, authentication passwords
will be encrypted.
Note: When the realm is changed, all stored SIP passwords
will be invalid.
SIP Configuration - DTMF signalling
Send as RTP (Optional) If enabled, keypad signaling will be sent as RTP event codes.
Offered RFC2833 payload type Default value: 96
Send as SIP INFO (Optional) If enabled, keypad signalling will be sent as SIP INFO mes-
sages.
Tone duration(msec) Enter the time length of the tone in milliseconds.
Default value: 270 msec
SIP Configuration - Message waiting indication
Enable indication (Optional) If enabled, MWI is displayed in the handset.
Enable subscription (Optional) If enabled, you can subscribe to MWI indications from the
SIP proxy.
