5A-84 Automatic Transmission/Transaxle:
Connector “C35”
Terminal Wire color Circuit
Standard
voltage
Condition
1RED
Transmission range
sensor (“R” range)
8 – 14 V Ignition switch ON, select lever at “R” range
0 – 1 V Ignition switch ON, select lever at other than “R” range
2— — — —
3— — — —
4— — — —
5— — — —
6WHT
Input shaft speed
sensor (+)
2 – 3 V Ignition switch turned ON, engine stops.
*(“Referenc
e waveform
No. 4: ”)
While engine running.
(Output signal is waveform. Waveform frequency varies
depending on output shaft speed. (16 pulses are
generated par 1 input shaft revolution.))
7GRN
Transmission range
sensor (“D” range)
8 – 14 V Ignition switch ON, select lever at “D” range
0 – 1 V Ignition switch ON, select lever at other than “D” range
8 GRN/ORN
Transmission range
sensor (“N” range)
8 – 14 V Ignition switch ON, select lever at “N” range
0 – 1 V Ignition switch ON, select lever at other than “N” range
9— — — —
10 — — — —
11 — — — —
12 PPL/YEL
Diagnosis switch (if
equipped)
8 – 14 V Ignition switch ON
13 — — — —
14 — — — —
15 — — — —
16 BLK
Input shaft speed
sensor (–)
2 – 3 V Ignition switch ON, engine at stop
17 — — — —
18
LT GRN/
BLK
Transmission range
sensor (“L” range)
8 – 14 V Ignition switch ON, select lever at “L” range
0 – 1 V Ignition switch ON, select lever at other than “L” range
19 GRN/YEL
Transmission range
sensor (“2” range)
8 – 14 V Ignition switch ON, select lever at “2” range
0 – 1 V Ignition switch ON, select lever at other than “2” range
20 PNK/BLK
Transmission range
sensor (“P” range)
8 – 14 V Ignition switch ON, select lever at “P” range
0 – 1 V Ignition switch ON, select lever at other than “P” range
21 — — — —
22 — — — —
23 PPL/WHT Data link connector 8 – 14 V Ignition switch ON
24 — — — —
25 PPL
Output shaft speed
sensor
8 – 14 V Ignition switch ON
*0 – 1 V
↑↓
10 – 14 V
(“Reference
waveform
No. 5: ”)
Vehicle running.
(Sensor signal is pulse. Pulse frequency varies
depending on vehicle speed. (8190 pulses are
generated par 60 km/h, 37.5 mile/h)
26 — — — —
