SVAN 948 USER MANUAL
5 - 59
RESULTS SEL. position which enables the user to select files with measurement’s results with H-A
data;
PARTIAL EAV/ELV position which displays the partial result of dose;
PARTIAL EXP. position which displays the result of exposure;
DAILY EXPOSURE position which displays the result of daily exposure.
The user can select available position select from the main list, using the <
>, <
> (or <
>,
<
>) push-buttons, the display text is highlight inversely. In order to confirm the selection the <ENTER>
push-button has to be pressed. After this confirmation the opened window or list is closed. In order to
ignore any changes made in the opened window or list the user has to press the <ESC> push-button.
The view of the displays with the HAV CALCULATOR sub-list
Selection of the file with result of measurement - RESULT SEL.
The RESULT SEL. position (path: MENU / AUX. FUNCTIONS / HAV/WBV CALC. / HAV CALCULATOR
/ RESULTS SEL.) is used to load data file from the FLASH DISC. User selects which files of measurement
should be used to determine results of measurements. It is possible to select 6 files, which include
measurement’s results with H–A data. The position is opened after pressing the <ENTER> push-button
when the RESULTS SEL. text in the HAV CALCULATOR list is displayed inversely (selected using the
<
>, <
> (or <
>, <
>) push-buttons). The return to the AUX. FUNCTIONS list is possible after
pressing the <ESC> push-button.
The view of the display in the HAV CALCULATOR sub-list the RESULT SEL text highlighted (displayed
inversely)
After pressing the <ENTER> push-button the position is closed and the instrument opens new sub-
list. It consists of six positions. The user can rewind the list using the <
>, <
> (or <
>, <
>) push-
buttons and select position after pressing <ENTER>.
The view of the display in the RESULTS SEL. list
In order to enter the file the user has to select position using the <
>, <
> (or <
>, <
>) push-
buttons and press the <ENTER>.
